Facilities

SILO Facilities

SILO Facilities
  • Storage capacity
    • 94 SILO bin : 171,000 M/ton(ABC Group 81 bin, D Group 13 bin)
    • Ware-house : 13,000 M/Ton
  • Fumigation
    • 10 SILO bin : 25,000 M/ton
  • Others
    • 3 hopper scale for loading , unloading & circulation
    • Dust explosion protection system by FENWAL system in U.S.A

하역시설 조감도

Unloading Facilities

Unloading Facilities
  • Mechanical type 2 Unload
    • 750 ton/hr 2-belt type unloader by S.Carves in U.K
    • 750 ton/hr 2-belt type unloader by Vigan in Belgium
  • Belt Conveyor loading facility for coastal transportation
    • The maximum loading capacity : 400ton/h
    • Have patent right for dust reduction facility during the loading
    • Be able to come alongside the berth up to DWT 2,000ton

Marine Facilities 조감도

Marine Facilities

Marine Facilities
  • 2 Private Berth for Exclusive Use
  • DWT 60,000MT x 1 (L 185M x W 13M x D 13M)
  • DWT 2,000MT x 1 for coastal freighter

저장시설 조감도

Storage Facilities

Storage Facilities
  • ABC Group (general 3 SILO)
    • Storage capacity : 125,000 ton
  • D Group (Exclusive SILO for Specific cargo)
    • Storage capacity : 46,000 ton of staple grains / 30,000ton of subsidiary grains
    • Installation of Auger system : Prevention of material hardness and inducement of fist in and out
  • Exclusive storage for Specific cargo
    • Capacity : 13,000 ton of staple grains / 11,000 ton of subsidiary grains
    • Mechanized storage : Prevention of damage products and Optimum quality maintenance
  • Grain temperature measuring devices, Grain high level sensing function automatic controller facility
    • Operating all storage for the best quality management
  • HMI(Human Machine Interface) System
  • Delivery facility on account of rain
  • Rewarehouse facility for overloaded cargo and down grains

저장시설

출고시설 조감도

Trucking Facilities

Trucking Facilities
  • 45 EA Units Truck Loading spout
    • ABC Group 34 EA + D Group 11 EA
  • Weighing : 2 EA
    • Weighing automation program
    • Unmanned release system
    • Release out in spite of weather and time
